ALPHA ELETTRONICA SR - ALPBLF-E24100M BATTERIA LITIO 25.6V 100AH 2560WH - BLF-E24100M

General characteristics
Technology: LiFePO4
Control interface: RS485
Cycle life: 6000

Electrical Features
Voltage:25.6V
Capacity: 100Ah
Energy : 2.56KWh
Max Charging current: 100A
Tensione di carica stand-by: 28.8V
Max. Discharging Current: 100A
Recommended discharging current: 50A
End of Discharge Voltage: 20.8V
Prof.di scarica raccomandata: 80%
Parallel Support: 2 max
Series Support: 2 max
Protections: Over load, Over discharge, Over temperature, Low temperature, Over current, Short circuit

Mechanical Characteristics
Dimensions: 480mm x 200mm x 170mm
Peso: 23.8Kg
IP rating: IP65
Connections: screw M6
Housing material: Metallico
Storage temperature: 5 / 35°C
Charge Temperature: 0 / 50°C
Discharge Temperature:60°C
Humidity: 20 / 80%
